An ISO 9001:2015 Company
Light Weight Level Transmitter
14500.00 INR/Piece
Product Details:
- Frequency 50 Hz Hertz (HZ)
- Weight 1.0 Kilograms (kg)
- Product Type Liquid Level Transmitter
- Temperature Range -20 to +70 C Celsius (oC)
- Connectivity Type threaded or flanged connections,
- Capacity 0-1,...,200 mH2O
- Size Compact Size
- Click to View more
X
Light Weight Level Transmitter Price And Quantity
- 1 Piece
- 14500.00 INR/Piece
Light Weight Level Transmitter Product Specifications
- Hydrostatic level transmitter
- Silver & Black
- 1mH2O to 200mH2O
- - Level measurement- Hydraulic monitoring in rivers and sea- Muddy liquid level measurement- Water treatment- Water diversion project- Sewage treatment plant-Diesel-Oil-Sea water
- 12 to 80 VDC
- Compact Size
- 4-20 mA
- 0-1,...,200 mH2O
- -20 to +70 C Celsius (oC)
- 0-1,...,200 mH2O
- threaded or flanged connections
- Liquid Level Transmitter
- 1.0 Kilograms (kg)
- 50 Hz Hertz (HZ)
- Analog Only
- Stainless steel
Light Weight Level Transmitter Trade Information
- Cheque Cash Against Delivery (CAD) Cash in Advance (CID)
- 150 Piece Per Week
- 4 Week
- No
- Contact us for information regarding our sample policy
- Wood & Plastic Box
- All India
- MSME, ISO, GST, BIS,
Product Description
Applications of Light Weight Level Transmitter
TLH is a Level sensor for hydrostatic level measurement
Drinking water dam water bore well well etc
Suitable for top mounting
Process temperature max 80 C
Process pressure max 200 mHZO
Suitable for corrosive liquids
Light Weight Level Transmitter Features
Compact size
4corel shielded cable with vent hose which is mechanically strong enough for deep submersible
liquid level measurements
Wide range industrial DC power supply 12 to 36 VDC
Loop powered device truetwo wire
No calibration required
Customized process connections like ThreadedFlangedHygienic etc
Accuracy 05 of F8 or 025 of FS
Remote Process Indicator Controller available on request
Light Weight Level Transmitter Technical Specifications
Application
Continuous level transmitter for Water Tanks Dam Water Bore Holes WaterWater Based
Slurry Liquid etc
Probe Length
1 mH2O to 200mH2O
Version Material
Compact Separate Sensing Diaphragm SS 304316316L
Process Connection
Threaded NPTBSP 12 to2
Flanged ANSIJISDINASA and customized process connection
Process Temperature
2070C
Process Pressure
ATM
Accuracy
050 of FS Standard
025 of FS Optional
Power Supply
1236Vdc
Signal Output
Two Wire 420mA loop powered RS485
ModBusRTU
Approvals
Conformity of Europa CE Weatherproof IP68 as per IS 13947
Advantages
Accurate measurement in big tanks and bore holes No configuration needed in field
