Power Supply |
80-260VAC, 50/60Hz for AC and 18 to 32VDC for DC |
Relay Output |
2/3 SPDT |
Relay Rating |
SPDT 5 A each @ 24VDC and 5A each @ 220VAC |
Output re-transmission lsolated power supply |
24V +/- 4V Suitable for maximum 25mA load |
Re-Transmission output |
4-20mA, Error @ 21mA, galvanically isolated loop powered section for use with either integrated ICT Isolated Loop Supply or any external DC supply within range 16 to 50VDC |
Transmitter power supply (for sensor) |
24V +/- 4V current limited at 25 mA |
Sensor interconnection cable type |
Shileded 2 Core PVC cable with 1 to 1.5 mm2 conductors cross section |
Max sensor cable length |
cable series resistance not to exceed 50 Ohm 1000 m for two-core 1 sq mm 2000 m for two core 1.5 sq mm conductor cross section. |
Ambient Temperature |
-10 C to 70 C |
Enclosure material |
Cast aluminum will polycarbonate see-through cover. |
Cable Entry |
3 cable entries suitable for PG-11, 1/2" NPT and 1/2"BSP |
Ingress Protection |
IP65 for Aluminum HAN enclosure IP40 for sheet metal special types. |
