Vibrating Fork Liquid Level Switch
13500.0 INR/Piece
Product Details:
- Phase single
- Material stainless steel
- Temperature Range -20 to 80 Celsius (oC)
- IP Rating IP67/68
- Features small size, universal power supply, low power consumption, and lack of calibration requirements
- Display Type No Display
- Protection Level IP67/68
- Click to View more
X
Vibrating Fork Liquid Level Switch Price And Quantity
- 13500.0 INR/Piece
- 1 Piece
Vibrating Fork Liquid Level Switch Product Specifications
- -20 to 60 Celsius (oC)
- -20 to 80 Celsius (oC)
- stainless steel
- 10
- top mounting and side mounting optional
- single
- IP67/68
- No Display
- Level switch
- small size, universal power supply, low power consumption, and lack of calibration requirements
- IP67/68
- Silver and Orange
Vibrating Fork Liquid Level Switch Trade Information
- 150 Piece Per Month
- 4 Week
- No
- Contact us for information regarding our sample policy
- Wood & Plastic Box
- All India
- MSME, GST,ISO
Product Description
Vibrating Fork Level switch-LFV
Believing ona fair believing policies, we are engrossed in providing a quality assured array of Vibrating Fork Liquid Level Switch. For detecting liquid levels, it is widely used in various industries such as food, beverages, chemical, petrochemical, mining and plastic. Offered switch is manufactured using top grade components under the direction of our experts. This Vibrating Fork Liquid Level Switch is ideal for detecting the state of objects by producing vibrations into them.
Key Points:
Key Points:
- Non corrosive structure
- Capable to work in extreme pressure and temperature
- Easy to mount
Product details
| Ambient Temp | -20 to 60 deg C |
| Extended Process | -30 to 200 deg C |
| Insertion length | 50mm to 3000mm |
| Max Viscosity | 10,000 cStokes (= cPose/(g/cm3)) (Higher viscosity available on request) |
| PNP with DC Supply | 12 to 60 VDC |
| Process Pressure | absolute / max. 15 bar |
| Process Temp | -20 to 80 deg C |
| Two wire AC with Series Relay | 18 to 260 VAC |
| Universal In DPDT Output | 15 to 80 VDC |
| Brand | Trumen |
