Compact Vibration Fork Point Level Switch

Compact Vibration Fork Point Level Switch

10400.0 INR/Piece

Get a Price/Quote

Product Details:

Mechanical Life Long
Rated Voltage 12 to 80 VDC or 18 to 260 VAC
Protection Level IP-65/67
Rated Current 250mA
Temperature Range -20 to 60 deg C Celsius (oC)
Circuit Type PNP, NPN, NAMUR, etc.
Frequency 10-55Hz
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Compact Vibration Fork Point Level Switch Price And Quantity

Price 10400.0 INR/Piece
Minimum Order Quantity 1 Piece

Compact Vibration Fork Point Level Switch Product Specifications

Operating Temperature -30 to 150 deg C Celsius (oC)
Weight 300 Grams (g)
Size 50 mm excluding threads
Current Rating 250mA max
Protection Level IP-65/67
Rated Current 250mA
Temperature Range -20 to 60 deg C Celsius (oC)
Finish Type stainless steel
Max. Current 12 to 60 VDC Volt (v)
No Of Poles DPDT
Response Time 1 sec
Max. Voltage 12 to 60 VDC
Power Rating 15 to 80 VDC and 15 to 260 VAC
Material Stainless Steel
Color Black & Silver
Mechanical Life Long
Rated Voltage 12 to 80 VDC or 18 to 260 VAC
Frequency 10-55Hz
Circuit Type PNP, NPN, NAMUR, etc.
Product Type Level Switch
Mounting Type Top/Side
Stoke 10

Compact Vibration Fork Point Level Switch Trade Information

Payment Terms Cheque, Cash Against Delivery (CAD), Cash in Advance (CID)
Supply Ability 100 Piece Per Month
Delivery Time 5 Week
Sample Available No
Sample Policy Contact us for information regarding our sample policy
Packaging Details as per product dimensions
Main Domestic Market All India
Certifications MSME, ISO, GST,

Product Description

https://trumen.in/tuning-fork-point-level-switch.html

Compact Vibrating Fork Level switch-LFV12

Offered Compact Vibration Fork Point Level Switch is not just applicable for point level measurement, as it has versatility in its applications. It is available with an oscillating division that gets vibrated in air with a certain frequency. The main benefit of the offered switch is that remains immune to foam, vibration, flow, bubbles, coating, solids content and some others. It ensures reliability in both high as well as low level applications. As it is not suitable for a high viscous media, its utilization must be prevented in such applications. Compact Vibration Fork Point Level Switch is functional for both top & side mounting. There is no requirement of calibration and thus cost-effectiveness is ensured for end-users. It efficiently detects the absence as well as presence of solid as well as fluid materials.

Product details

Ambient Temp	-20 to 60 deg C
Enclosure Material	SS316
Extended Process	-30 to 150 deg C
Max Viscosity	10,000 cStokes (= cPose/(g/cm3)) (Higher viscosity available on request)
Output Limit	250mA max. Short Circuit Safe.
Power Supply	12 to 60 VDC
Process Pressure	absolute / max. 15 bar
Process Temp	-20 to 80 deg C
Sensor Insertion Length	LFV12 : 50 mm excluding threads LFV11 : 128 mm including threads
